Ag-Bag G6070P User Manual
Page 3
Section 1 - Frame, Rotor, Cable Drums, Tunnel Top, Tunnel Extensions &
Bag Boom
1.01 Frame with Rotor & Cable Drums.................................................................................................6
1.01.1 Frame with Rotor & Cable Drums - G6070P.............................................................................8
1.02 Tunnel Top Interchangeable, Tunnel Extensions & Bag Cradle...................................................10
Section 2 - Wheels, Tires, Spindle & Hub Assembly
2.01 Spindle & Hub Assembly - G6060, G6070 & G6070P................................................................12
2.02 Wheels & Tires............................................................................................................................14
Section 3 - Conveyor, Drive Assembly & Hopper Assembly
3.01 Drive Assembly - Rotor...............................................................................................................16
3.02 Hopper Assembly.......................................................................................................................18
3.03 Split Conveyor - G6060, G6070 & G6070P (S/N 42.04939 & Before)........................................20
3.04 Split Conveyor (S/N 42.04940 & After).......................................................................................24
3.05 Lower Assembly, Split Conveyor - G6060, G6070 & G6070P (S/N 42.04940 & After)...............28
3.06 Single Conveyor..........................................................................................................................30
3.07 Conveyor Support/Slide Assembly, Split & Single Conveyor......................................................34
3.08 Conveyor Lift Assembly - Manual...............................................................................................36
3.09 Hydraulic Conveyor Lift Kit - G6060, G6070 & G6070P.............................................................38
Section 4 - Brake Assembly, Cable Guide Assembly, & Bag Boom
4.01 Brake Assembly - G6070 & G6070P..........................................................................................40
4.02 Cable/Guide Assembly...............................................................................................................42
4.03 Bag Boom...................................................................................................................................44
Section 5 - Backstop & Jackstand
5.01 Backstop, Steel...........................................................................................................................46
5.02 Jack Stand - G6060, G6070 & G6070P......................................................................................48
Section 6 - Transport Lights, Safety Signs & Decals
6.01 Transport Lights & Light Stand - G6060, G6070 & G6070P.......................................................50
6.02 Safety Signs & Decals - G6060, G6070 & G6070P....................................................................52
7.01 Gearbox, Dual Output Aluminum................................................................................................54
7.01.1 Gearbox, Dual Output Cast Iron..............................................................................................56
8.01 PTO Transport Kit - G6060 & G6070..........................................................................................58
8.01.1 PTO Transport Assembly - G6070P.........................................................................................60
8.02 PTO Shaft - G6070 & (G6060 2009 Production & After)............................................................62
8.02.1 PTO Shaft - G6070P................................................................................................................64
G6070/G6070P
- 3 -
42.0901805A Issue Date: 10/11
Table of Contents
