Guide, Cable Rewind, Right.....27
Guide, Chain Conveyor - Left (G6060 &
PB6000 Only) Not Shown.....20
Guide, Chain Conveyor - Right (G6060 &
PB6000 Only) Not Shown.....20
H
Half Shaft, Cleared (Not Serviced
Separately).....39
Half Shaft, Uncleared (Not Serviced
Separately).....39
Half Shield Kit (Not Serviced Separately)....39
Harness, Lights (Includes Item 17).....33
Hhdnut - Lock 1/4 Whiz.....51
Hitch, Field, 8-9 Ft w/Decals.....7
Hold Down, Conveyor.....23
Holder, Plug Storage.....33
Housing, R700 TAP 1/2-14 Side.....37
Housing, R700 THRU Improved.....37
Hub Assembly With Cups & Studs (Includes
Items 6 thru 8).....11
I
I.Cone, Shield Cone, #5-6-7 Inner (Not
Serviced Separately).....39
Inoculant, Granular, 50 lb Bucket (Treats 100
Ton).....43
Inoculant, Liquid 250 Ton Foil Pouch For Inject.
Sprayer.....43
Inoculant, Liquid 50 Ton Foil Pouch.....43
Instruction Booklet (Not Serviced).....39
J
Jack, Manual, 15 in. Square Mount.....7
K
Key, 5/8 x 5/8 x 1.945.....37
Key, 5/8 x 5/8 x 2-3/4 in......15
Key, Shaft (Hydraulic Motor).....19, 41
Key, Sq, 3/4 x 3/4 x 4 in. - (G6060 S/N
42.05167 & Before) & PB6000 Only.....15
Key, Sq, 7/8 x 7/8 x 4 in. - G6070 & (G6060
S/N 42.05168 & After).....15
Key, Square, 3/8 in. x 3 in. Undersize.....7
Kit, Ball Collar, 1-3/8 in. #6.....39
Kit, Bungee Cord (Consists Of Items 11a &
11b).....9
Kit, RT Ball Collar S5/S9, 1-3/4 in......39
Koster Moisture Tester - Not Shown.....43
L
Lens, Amber (Command).....33
Lens, Amber (Wesbar).....33
Lens, Red (Command).....33
Lens, Red (Wesbar).....33
Light, Dual Lamp, Amber/Red, Left Side.....33
Light, Dual Lamp, Amber/Red, Right Side...33
Link, #120-2 Connector UST.....15
Link, CA550 Connector.....19
Link, CA550 Offset.....19
Link, Offset, #120-2.....15
Liquid Inoculant Applicator, 15 Gallon Sprayer
- Not Shown.....43
Liquid Inoculant Applicator, 27 Gallon Sprayer
- Not Shown.....43
Liquid Inoculant Applicator, 55 Gallon Sprayer
- Not Shown.....43
Lug Nut, 1/2-20.....11
M
Master Seal Zip Tool.....43
Master Seal, 14.5 ft Lengths 4/Box For 8 & 9
ft Bags.....43
Master Seal, 17 ft Lengths 4/Box For 10 ft
Bags.....43
Master Seal, 20 ft Lengths 4/Box For 11 & 12
ft Bags.....43
Master Seal, 250 Ft Roll.....43
Master Seal, 9.5 ft Lengths 4/Box.....43
Motor, Electric, w/Brackets & Harness.....47
Motor, Hydraulic, 101-1019-009, 5.9 cu. in.
(PB6000 Only).....19
Motor, Hydraulic, 101-1751-009, 7.3 cu. in.
(G6060 & G6070 Only).....19
Motor, Hydraulic, Charlyn, 101-1019.....41
Mount, (Weld On), Jack, Female Square
Tubing.....7
Mount, Gandy Applicator.....49
Mount, Hydraulic Motor (G6060 & PB6000
Only).....19
N
Nut, Hex Lock, 1/2-13.....20
Nut, Hex Lock, 1/2-13 Nylock.....7, 49
Nut, Hex Lock, 1/4-20.....20
Nut, Hex Lock, 1/4-20 Nylock.....33
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
- G6060 & PB6000.....17
Nut, Hex Lock, 1/4-20 Nylock Stainless Steel
- G6070 & G6070P.....17
Nut, Hex Lock, 3/4-10 Nylock.....7, 15
Nut, Hex Lock, 3/8-16.....20
Nut, Hex Lock, 3/8-16 Nylock.....9, 29, 33, 49
Nut, Hex Lock, 3/8-16 Nylock Stainless
Steel.....9
Nut, Hex Lock, 5/8-11 Nylock.....7, 9, 23, 29,
31
Nut, Hex Nylon Flange Lock, 3/8-16 Yellow
Zinc.....23
Nut, Hex Slotted, 7/8-14.....11
Nut, Hex Top Lock, 5/8-11.....45
Nut, Hex Whiz Lock, 3/8-16.....25
Nut, Hex, 1/2-13.....15, 19
Nut, Hex, 3/4-10.....45
O
O-Ring, Rubber, Gandy.....47
Oil Seal.....11
P
Pan, Bag G6060 & PB6000.....9
Pan, Bag G6070 & G6070P Only.....9
Panel, Hopper Extension, Front 6 Ft w/Decals
- G6060 & PB6000 Only.....17
Panel, Hopper Extension, Front 7 Ft - G6070
& G6070P Only.....17
Panel, Hopper Extension, Right Side.....17
Panel, Sloped, Hopper 6 Ft - G6060 & PB6000
Only.....17
Panel, Sloped, Hopper 7 Ft - G6070 & G6070P
Only.....17
Pin, Cam Lever.....23
Pin, Clevis, 5/8 in. x 1-1/2 in. Zinc.....25
Pin, Cotter, 5/32 in. x 1-1/4 in. Stainless
Steel.....25
Pin, Cotter, 5/32 x 1-1/4 in. Stainless
Steel.....27
Pin, Cotter, 5/32 x 2 in......11
Pin, Hair.....7
Pin, Hitch.....7
Pin, Roll, 3/8 in. x 2 in. (G6060 & PB6000
Only).....19
Pin, Spring, 5/32 in. x 1-1/4 in......23
Pinion Gear.....37
Plate, Conveyor End Deflector w/Decals.....19
Plate, Face, 86 in......17
Plate, Light Mount Weldment.....33
Plug, 1/2-14 NPT, Socket Head.....37
Plug, Light Cord (Included In Item 16).....33
Plug, Vent, 5 psi.....37
Polyethelene, High Density (Used On G6060
& PB6000 Only).....20
PTO Shaft, Complete.....39
Pulley (G6060 & PB6000 Only).....19
Pulley, 2-1/2 in. OD x 1/4 in. Cable x 5/8 in.
ID.....25
Pulley, Bag Boom, 3 in. UHMW.....29
Pulley, Swivel (G6060 & PB6000 Only).....19
R
Repair Tape, 2 in. x 36 Yard Roll - Not
Shown.....43
Repair Tape, 3 in. x 36 Yard Roll - Not
Shown.....43
Repair Tape, 4 in. x 36 Yard Roll - Not
Shown.....43
Retainer, Bearing.....47
Retaining Ring, External, 1.938.....37
Rod, Cable Rewind.....27
Rod, Chain Tensioner.....15
Rope, Backstop, 3/8 x 300 Ft (8-9 Ft
Backstop).....31
Rope, Backstop, 3/8 x 400 Ft (10 Ft
Backstop).....31
Rotor + Three Teeth & Caps - (Weld
Req`d).....7
Rotor, Gandy, Jumbo 10 in. Rubber.....47
Rubber Latch, 3 in. (G6060 & PB6000
Only).....19
Rubber Latch, 5 in. (G6060 & PB6000
Only).....19
S
Safety Sign, Caution 540 RPM.....35
Safety Sign, Danger, Conveyor
Entanglement.....35
Safety Sign, Danger, Rotating Drive Line....35
Safety Sign, Danger, Rotor Entanglement...35
S a fe t y S i g n , Wa r n i n g C a b l e
Entanglement.....35
Safety Sign, Warning, Before Operating.....35
Safety Sign, Warning, Foot Crushing.....35
PB6000 - 55 - 42.0901803A Issue Date: 09/11
Part Description Index
(continued)
