Section 1 - Frame, Rotor, Cable Drums, Tunnel Top, Tunnel Extensions &
Bag Boom
1.01 Frame with Rotor & Cable Drums PB6000...................................................................................6
1.02 Tunnel Top Interchangeable, Tunnel Extensions & Bag Cradle.....................................................8
Section 2 - Wheels, Tires, Spindle & Hub Assembly
2.01 Spindle & Hub Assembly - PB6000............................................................................................10
2.02 Wheels & Tires............................................................................................................................12
Section 3 - Conveyor, Drive Assembly & Hopper Assembly
3.01 Drive Assembly - Rotor...............................................................................................................14
3.02 Hopper Assembly.......................................................................................................................16
3.03 Single Conveyor..........................................................................................................................18
3.04 Conveyor Support/Slide Assembly, Split & Single Conveyor......................................................22
3.05 Conveyor Lift Assembly - Manual...............................................................................................24
Section 4 - Brake Assembly, Cable Guide Assembly, & Bag Boom
4.01 Cable/Guide Assembly...............................................................................................................26
4.02 Bag Boom...................................................................................................................................28
Section 5 - Backstop & Jackstand
5.01 Backstop, Steel...........................................................................................................................30
Section 6 - Transport Lights, Safety Signs & Decals
6.01 Transport Lights & Light Stand - PB6000....................................................................................32
6.02 Safety Signs & Decals - PB6000................................................................................................34
Section 7 - Gearbox
7.01 Gearbox, Single Output..............................................................................................................36
Section 8 - PTO Driveline
8.01 PTO Shaft - PB6000 & (G6060 up to 2009 Production).............................................................38
Section 9 - Hydraulics & Breather Assembly
9.01 Hydraulic Drive Assembly - Single Conveyor.............................................................................40
Section 10 - Miscellaneous Items, Options & Kits
10.01 Miscellaneous Items.................................................................................................................42
10.02 Safety Chain Kit........................................................................................................................44
10.03 Gandy, 45 lb. Dry Inoculant Applicator......................................................................................46
10.04 Gandy Box - PB6000................................................................................................................48
10.05 Option: Conveyor Liner.............................................................................................................50
PB6000 - 3 - 42.0901803A Issue Date: 09/11
Table of Contents
