The Part Description Index is an alphabetical index of all part descriptions included in this manual. The index shows what page(s) the part
is used on.
A
Adapter, Swivel.....20
Angle, Slide Frame Clamp (G6060 & PB6000
Only).....20
B
Backstop, 10 Ft - G6070 & G6070P Only....31
Backstop, 8-9 Ft - G6060 & PB6000 Only...31
Bar, Adjustable Chain Tensioner.....15
Bearing Cone, 2.750 VN-33275.....37
Bearing Cone, TMKN# 5565.....37
Bearing Cone, TMKN# HM807044.....37
Bearing Cup, 4.125 VN-HM807010.....37
Bearing Cup, 4.6250 VN-33462.....37
Bearing Cup, TMKN# 5535.....37
Bearing, 1 in. - 2 Bolt Flange.....19
Bearing, 2 Bolt Flange (G6060 & PB6000
Only).....19
Bearing, 4 Bolt Flange.....7
Bearing, Drive, 2-15/16 in. 4 Bolt Footed.....7
Bearing, Drive, 3-7/16 in. Spherical 4 Bolt
Footed - (G6060 S/N 42.05168 & After).....7
Bearing, Gandy.....47
Bearing, Split Babbit.....7
Bird Netting, 30 x 100 Ft - Not Shown.....43
Bird Netting, 30 x 375 Ft - Not Shown.....43
Bird Netting, 30 x 500 Ft - Not Shown.....43
Bolt Bag, Tunnel Extension (Consists Of Items:
8, 16 & 17).....9
Bolt Bag, Tunnel Hardware (Consists Of Items:
3 thru 6).....9
Bolt, Button Hd, 1/4-20 x 1-1/2 in. Stainless
Steel.....17
Bolt, Button Hd. 3/8-16 x 1 in. Stainless
Steel.....9
Bolt, Hex, 1/2-13 x 1-1/2 in. Gr 5.....7
Bolt, Hex, 1/2-13 x 1-3/4 in. Gr 5.....7
Bolt, Hex, 1/2-13 x 3-1/4 in. Yellow Zinc.....33
Bolt, Hex, 1/4-20 x 1/2 in. Gr 5.....33
Bolt, Hex, 1/4-20 x 3/4 in. Gr 5.....33
Bolt, Hex, 1/4-20 x 3/4 in. Stainless Steel -
G6060 & PB6000 Only.....17
Bolt, Hex, 1/4-20 x 3/4 in. Stainless Steel -
G6070 & G6070P Only.....17
Bolt, Hex, 3/4-10 x 2-1/4 in. Gr 5.....45
Bolt, Hex, 3/4-10 x 3 in. Gr 5.....15
Bolt, Hex, 3/4-10 x 3-1/2 in. Gr 5.....7
Bolt, Hex, 3/4-10 x 5-3/4 in......15
Bolt, Hex, 3/8-16 x 1 in. Yellow Zinc.....25
Bolt, Hex, 3/8-16 x 1-1/4 in. Gr 5.....23, 29
Bolt, Hex, 3/8-16 x 2 in. Gr 5.....23
Bolt, Hex, 3/8-16 x 2-1/2 in. Gr 5.....29
Bolt, Hex, 3/8-16 x 4 in. Stainless Steel.....9
Bolt, Hex, 5/16-18 x 2-1/2 in. Gr 5.....41
Bolt, Hex, 5/16-18 x 3/4 in. Gr 5 Special.....15
Bolt, Hex, 5/8-11 x 1-1/2 in. Gr 5.....23
Bolt, Hex, 5/8-11 x 2 in. Gr 5.....7
Bolt, Hex, 5/8-11 x 2-1/2 in. Gr 5.....7, 9
Bolt, Hex, 5/8-11 x 3 in. Gr 5.....29
Bolt, Hex, 5/8-11 x 3-1/2 in. Gr 5.....45
Bolt, Hex, 5/8-11 x 5 in. Gr 5.....31
Bolt, SHCS, 1/2-13 x 2-1/4 in. Gr 8.....37
Bolt, SHCS, 3/8-16 x 2-1/4 in......37
Bottom/Slide, 4 Hole Straight, Jumbo.....47
Bracket, Gandy Applicator.....49
Bracket, Light, Left Side w/Decals.....33
Bracket, Light, Right Side w/Decals.....33
Bracket, Skirting - Small (G6060 & PB6000
Only).....19
Bulb, #1157.....33
Bungee Cord, Bag Pan.....9
Bungee Cord, Tunnel.....9
Bushing, 1/2 NPT To 1/8 NPT.....37
Bushing, Machine, 1/2 in. x 14 Ga......23
C
Cable Drum, Brake Side, 6 Ft Rotor.....7
Cable Drum, Non Brake Side, 6 Ft Rotor.....7
Cable, 1/4 in. x 17 Ft. (G6060 & PB6000
Only).....19
Cable, 1/4 x 30 Ft, w/Hook.....29
Cable, 7/16 x 195 Ft......27
Cable, Conveyor Lift, 1/4 in. x 17 Ft......25
Cap, Dust.....11
Cap, Rotor Tooth, Weld On.....7
Capscrew, Hex Hd. 1/2-13 x 1-1/2 in. Gr
5.....20
Capscrew, Hex Hd. 1/2-13 x 1-1/4 in. Gr
5.....49
Capscrew, Hex Hd. 1/2-13 x 6 in......19
Capscrew, Hex Hd. 1/4-20 x 1 in. Gr 5.....19
Capscrew, Hex Hd. 3/8-16 x 1 in. Gr 5......19,
49
Capscrew, Hex Hd. 3/8-16 x 1-1/2 in. Gr
5.....19
Capscrew, Hex Hd. 3/8-16 x 1-1/4 in. Gr
5.....19
Capscrew, Hex Hd. 3/8-16 x 2-1/2 in. Gr
5.....19
Capscrew, Hex Hd. 5/16-18 x 3/4 in. Gr 5....19
Cartridge, Pressure Relief Valve.....41
Chain, Conveyor Complete (G6060 & PB6000
Only).....19
Chain, Roller, #120-2 59P - G6060 & PB6000
Only.....15
Chain, Roller, #120-2, 7.875 Ft, 63 P, UST -
G6070 Only.....15
Chain, Safety.....45
Clamp, Cable (G6060 & PB6000 Only).....19
Clamp, Cable, 1/4 in......25
Clamp, Single, .63 in. I.D......33
Clamp, Vinyl, .38 in. dia......33
Clevis.....45
Complete Shield Kit.....39
Cone, Roller Bearing, 1-1/4 in......11
Cone, Roller Bearing, 1-5/8 in......11
Conveyor Complete (Used On G6060 &
PB6000 Only).....20
Conveyor End, Adjusting w/Decals (G6060 &
PB6000 Only).....19
Conveyor, Frame w/Decals (G6060 & PB6000
Only).....19
Coupler, Conveyor Motor (G6060 & PB6000
Only).....19
Coupler, Quick Disconnect, 1/2 in. Male, 1/2
NPTF.....41
Coupling, Cable Drum.....7
Cradle, Bag Boom, 10` - G6070 & G6070P
Only.....9
Cradle, Bag Boom, 8` & 9` - G6060 & PB6000
Only.....9
Cradle, Bag Boom, 9` - G6070 & G6070P
Only.....9
Cross Kit, #6, 30.2 x 91.4.....39
Cup, Bearing, Inner.....11
Cup, Bearing, Outer.....11
D
Danger Label, Outer Drive Tube.....39
Danger/Shield Label.....39
Decal, Ag-Bagger 6000 Series.....35
Decal, Ag-Bagger, 5 in. Blue.....35
Decal, Grease.....35
Decal, Grease Rotor Bearing.....35
Decal, Important, Lug Nuts.....35
Decal, Notice, Tractor Neutral.....35
Decal, Oil Chain.....35
Decal, Red Retroreflective, 2 x 9 in......33, 35
Decal, Yellow Retroreflective, 2 x 9 in.......33,
35
Door Assembly, Conveyor with Hooks.....20
Drum, Cable, w/Brake Flange, 7 Ft Rotor -
6070 Only.....7
E
End Cap, CP - 3.500 x .375.....37
F
Fitting, Grease (G6060 & PB6000 Only).....19
Fitting, Hose End Swivel (Use With Grease
Lines).....20
Flexible Roll Pin, #6/7 Inner, 10 x 65mm.....39
Flexible Roll Pin, #6/7 Outer, 10 x 75mm....39
Frame Weldment - with 8 Ft Tunnel Only.....7
Frame Weldment - with 9 Ft Tunnel Only.....7
Frame, Bag Boom, 8-10 Ft......29
Frame, Conveyor Slide.....23
G
Gandy Applicator - 4 Hole.....49
Gasket, Bearing Retainer, Gandy.....47
Gear.....37
Gearbox, Complete.....37
Gearbox, Single Output - PB6000 Only.....7
Grease Fitting, M6 x 1 Straight (Not Serviced
Separately).....39
Grease Line - 3/16 in. x 20.5 in. (Used On
G6070 Only).....20
Grease Line - 3/16 in. x 40 in. (Used On G6060
& PB6000 Only).....20
Guard, Conveyor Tail Shaft (G6060 & PB6000
Only).....19
Guard, Rotor Chain - G6060 & PB6000
Only.....15
Guard, Rotor Chain - G6070 Only.....15
Guide, Cable Rewind, Left.....27
42.0901803A Issue Date: 09/11 - 54 - PB6000
Part Description Index
