For assistance call 1.800.285.8315
PS Series Mounting System Instructions
PS-CTR (continued)
Step 3
Using the Buttonhead Bolt 1/4 x 3/4”,
bolt the Center Extension with
Acrylic to the Center Arm.
Step 4
Lock in PS-CTR to Central Support
using tabs. Adjust the length of the
PS-CTR and tighten Buttonhead
Bolt.
Step 5
Secure PS-CTR to Central Support
using Buttonhead bolt 1/4 x 1
