PS Series Mounting System Instructions
PS-ABV (continued)
Step 4
Bolt Acrylic onto L-Support Bracket
using the four Countersunk Bolts
and Acorn Nuts.
Step 2 Step 3
Slide PS-ABV into Central Support
and lock in place at desired height
using tabs.
Secure PS-ABV to Central Support
using the Buttonhead Bolt
