PS Series Mounting System Instructions
PS-CTR
Step 1
Acrylic
Center
Extension
Countersunk
Bolt
Acorn
Nut
Buttonhead
Bolt 1/4 x 3/4 Buttonhead
Bolt 1/4 x 1
Seperate pieces.
Step 2
Bolt Acrylic to Center Extension
using the four Countsunk Bolts and
for Acorn Nuts
Central Arm
x4
x1
x4
x1
