OPERATION (CONTINUED)
Leg Extension (Figure 9)
WARNING
The leg extension is not intended to be extended
during entry onto or exit off of the table. The leg
extension is not intended to be used as a seat.
Failure to heed this warning could result in serious
personal injury.
1. Pull leg extension out to the desired position. The up-
holstered pad on the leg extension will extend along
with the leg extension.
2. To slide the upholstered pad off the leg extension, lift
the front end of the pad (while holding the leg exten-
sion) and slide back to the stowed position.
3. To remove the upholstered leg extension pad, fully
extend the leg extension and lift the upholstered pad
off the leg extension.
Treatment Pan (Figure 9)
1. To use the treatment pan, pull until leg extension is
fully extended.
2. Slide the upholstered pad on the leg extension back
into the stowed position or remove it completely.
3. Position the leg extension until the treatment pan is at
the desired location.
NOTE: The treatment pan can easily be removed for
cleaning when the leg extension is fully extended and the
leg extension pad removed or stored.
Figure 9. Leg Extension and Treatment Pan
Horizontal Positioning
Leg Extension Pad
Treatment Pan
Leg Extension
