Using Your ATI Multimedia Center 89
Check the Record mixer settings:
1 Click Start, point at Programs , point at Accessories ,
point at Entertainment , then select Volume Control.
Or, right-click the speaker icon (usually in the lower-
right corner of your screen), then click Open Volume
Controls.
2 In the Volume Control menu, click Options, click
Properties, click Recording, then click OK. The
Recording Control opens.
3 Ensure that Line (or the Audio input you selected in the
Sound Initialization Wizard — see
page 13 ) is checked,
then click to close the dialog.
Connect the VCR audio output to your PC:
• Left and right audio output from your VCR must be
connected to your ALL-IN-WONDER 128 family card or
ALL-IN-WONDER RADEON card (note that S-Video does
not provide an audio connection). For complete installation
instructions, refer to the ALL-IN-WONDER 128 /
ALL-IN-WONDER 128 PRO / ALL-IN-WONDER RADEON
Installation and Setup User’s Guide.
Can’t capture sound
Can’t capture sound when
recording from a videotape.
S-VIDEO
OUT
COMP.
VIDEO
OUT
L. AUDIO
OUT
R. AUDIO
OUT
ALL-IN-
WONDER
128
Family
card or
ALL-IN-
WONDER
RADEON
A/V IN
CATV
A/V OUT
OR
S L R
ATI Input Adapter
