Design Guide
THE INSTALLATION SPACE
Water And Electrical Locations
7KHRSHQLQJPXVWEHSUHSDUHGZLWKWKHHOHFWULFDO
and the cold water supply located as shown.
The cutout depth must be 24”
7KHUHIULJHUDWRUZLOOSURMHFWIRUZDUGVOLJKWO\EH\RQG
adjacent cabinetry, depending on your installation.
Cutout depth beneath a soffit:
When installed beneath a soffit, the soffit cannot
H[FHHGWKHµLQVWDOODWLRQGHSWKVKRZQ7KHWRSFDVH
trim overlaps the bottom of the soffit.
Additional Specifications
$YROW+]RUDPSSRZHUVXSSO\LV
required. An individual properly grounded branch
circuit or circuit breaker is recommended. Install
a properly grounded 3-prong electrical receptacle
recessed into the back wall. Electrical must be
located on the rear wall as shown.
NOTE:*),JURXQGIDXOWLQWHUUXSWHULVQRW
recommended.
7KHZDWHUOLQHFDQHQWHUWKHRSHQLQJWKURXJK
WKHIORRURUEDFNZDOO7KHZDWHUOLQHVKRXOGEHµ
2'FRSSHUWXELQJRU*(6PDUW&RQQHFW
™
kit between
the cold water line and water connection location,
long enough to extend to the front of the refrigerator.
Installation of an easily accessible shut-off valve
in the water line is required.
DIMENSIONS AND CLEARANCES
* Shipping height.
The refrigerator can
be adjusted to fit
into a cutout that
is 83-1/2” min. to
84-1/2” max. height.
Note that the top
case trim at the
front is 1/2” higher
and will overlap
upper cabinetry or
soffit. Use leveling
legs and wheels
for a maximum 1”
height adjustment.
Product Clearances
7KHVHUHIULJHUDWRUVDUHHTXLSSHGZLWKDSRVLWLRQGRRU
VWRS7KHIDFWRU\VHWGRRUVZLQJFDQEHDGMXVWHG
to 90° if clearance to adjacent cabinets or walls
is restricted.
3
*The finished cutout width must be:
35-1/2” for 36” models
41-1/2” for 42” models
47-1/2” for 48” models
90° Door Swing
130° Door Swing
*Finished Width
6"
5"
Electrical
Area
84 1/2" max
83 1/2" min
Finished
Opening
75" From Floor
to Bottom
of Electrical
Area
24"
5"
5"
3 1/2"
Water Supply
3 1/2"
36" Models 12"
42" Models 18"
48" Models 20"
$OORZPLQLPXPFOHDUDQFHVIRUWKHIUHH]HUGRRU
'LPHQVLRQ$DQGIUHVKIRRGGRRU'LPHQVLRQ%
for a full 130° door swing and to allow for pan removal.
)RUDGRRUVZLQJDOORZµPLQFOHDUDQFHWRDZDOO
IRUIUDPHGDQGVWDLQOHVVVWHHOPRGHOV$OORZµPLQ
clearance for professional series models. If the 90° door
stop position is used, pan access is maintained, but pan
removal is restricted.
See the illustrations on pages 4 and 5 to determine door
swing interaction with adjacent cabinets or countertops.
Models A B
C
36” 13”
15”
20-5/8”
42” 13”
19”
26-5/8”
48” 15”
20”
28-5/8”
*84" From
Floor to
Top Frame
25-3/8" Framed Models
25-3/4" Stainless Steel Models
Depth Including Handles:
26-7/8" Framed Models
27-3/4" Stainless Steel Models
28-11/16" Professional Models
36", 42" or 48"
Frame to Frame
35", 41", or 47"
Case Width
*83-1/2"
at
Rear
23-7/8"
Behind
Frame
C
90 Door Swing
*Min. Distance
to Wall
*4” Stainless and
Trimmed Models.
5” Pro Series
