36" Professional gas rangetop
36" Professional gas rangetop general features
Sealed, dual-flame stacked burners.
Provide complete low-
simmer-to-rapid-boil flexibility (140°F simmer to 18,000 BTUs*).
The burners are sealed to the recessed cooktop for easy cleaning.
Reversible burner grates. Are flat on one side and uniquely
contoured on the other to accommodate various-size woks.
Stainless steel and aluminum-clad griddle. Offers 18,000
BTUs* of power, allowing fast and consistent heating across the
entire cooking surface.
The ceramic-infrared grill. Has 14,000 BTUs* of adjustable
heat. The cooking grate is grooved on one side to create sear
marks and rounded on the other side for delicate foods.
For additional details on product installation, warranty coverage,
care and maintenance, visit monogram.com.
*Natural gas
36" Professional gas rangetops
ZGU366NPSS, ZGU364NRPSS and
ZGU364NDPSS (natural gas)
ZGU366LPSS, ZGU364LRPSS and
ZGU364LDPSS (liquid propane)
Overall dimensions
(WxHxD in inches):
35-7/8 x 8-1/2 x 27-1/2
Amps @120VAC
4.0– 4 burners
0.5– 6 burners
Approx. shipping wt. (lbs.) 228
BACK FRONT GRIDDLE BACK FRONT
ZGU364ND
Professional rangetops offer a number of choices in size and
cooktop configurations.
The rangetops are factory set for natural gas or liquid propane.
Be sure to order the correct model for the installation situation.
If the wrong fuel type is ordered, the rangetop may be converted.
Conversion orifices are packed with each product.
WB28K10553 high-altitude kit is available for operation above
6,000 feet. This kit includes orifices for both LP and natural
gas operation.
All conversion kits must be
installed by a qualified
service technician at an
additional cost.
Advance planning for 36" Professional gas rangetops
Electrical requirements
Rangetops must be supplied with 120V, 60Hz, and connected to
an individual, properly grounded branch circuit protected by
a 15-amp circuit breaker or time-delay fuse.
Gas supply
• Natural gas models are designed to operate at 5" water
column pressure. For proper operation, the pressure of the
natural gas supplied to the regulator must be between 7"
and 13" water column.
• The liquid propane models are designed to operate at 10"
water column pressure. For proper operation, the pressure of
the LP source to the regulator must be between 11" and 13"
water column.
The serial and model numbers are located behind the far left
knob for convenience. The full rating label is located on the
bottom of the rangetop.
• Offers three combinations
of burners, grill and griddle
• Natural or LP gas must be
specified by model number
• Optional 12" or 30"–36"
adjustable-height backsplash
accessories
• All burner grates are reversible
to support a round-bottom wok
36" rangetop surface configurations
The 36" Monogram ® Professional rangetops are available with a
combination of a grill or griddle and 4 burners, or simply 6 burners.
ZGU364NDPSS
with 4 burners and griddle
(Order ZGU364LDPSS for LP gas) ZGU364NRPSS
with 4 burners and grill
(Order ZGU364LRPSS for LP gas) ZGU366NPSS
with 6 burners
(Order ZGU366LPSS for LP gas)
