10
5(029((;+$867$'$3725
,IH[KDXVWLQJYHQWLQJXVLQJWKH 1 ø 4 s[s rectangular
GXFW³RSWLRQDOIRU-9-9-9-9-9
-9DQG$9PRGHOVRQO\
Remove the exhaust adaptor from the inside of the hood.
Set it aside along with its mounting screws.
3 1 ø 4 s x 10s
rectangular
exhaust
adaptor
and screws
REMOVE FILTER
Remove the shipping tape holding the metal grease
ILOWHUin place. Pull down on the center of the front edge
of the filter. The filter will then slip out of the retaining
tabs on the back.
5(9(56(7+(%$))/()25'8&7('
,167$//$7,21621/< -9-9
-9-9-9DQG$9PRGHOV
If the hood is to be recirculated, skip to the next step.
Remove the baffle from the top of the hood. Reinstall
the baffle so the short side marked “VENTED” is visible.
The long side of the baffle should be inside the hood.
REMOVE WIRING COVER
Remove the ZLULQJFRYHU from inside the hood.
Set the cover and its mounting screws aside.
Wiring
cover
5(029(:,5,1*.12&.287
Remove either the top or the back wiring knockout as
needed and install an approved VWUDLQUHOLHIFODPS.
2
3
4
6
Metal grease filter
Installation Instructions
“VENTED” is visible
Strain relief
clamp
Back
knockout
Top
knockout
Strain relief
clamp
5(029('8&7.12&.287
If recirculating, non-vented ductless (JN327 and RN328,
and optional for JV247, JV248, JV347, JV348, JV367 and
AV447 models only), VNLSWR6WHS'DQGSURFHHG
Using a flat-blade screwdriver, remove the appropriate
GXFWNQRFNRXW from the top or back of the hood.
3 1 ø 4 s[s Rectangular
YHUWLFDOGLVFKDUJH
Remove top rectangular
duct knockout only.
7s5RXQGYHUWLFDOGLVFKDUJH
Remove circular duct
knockout only.
3 1 ø 4 s[s Rectangular horizontal
discharge. Remove rear
rectangular duct knockout only.
7
