1 Paper-width guide
2 Paper-length guide
4. Adjust the paper-width and paper-length guides inward until they stop at the edges
of the paper.
5. Push the main tray all the way in.
1 Push in the main tray all the way
Load the photo tray
Use photo paper up to 10 x 15 cm (4 x 6 inch) with or without tabs, Hagaki cards, A6
cards, and L-size cards.
1.
Lift the output tray and extend the photo tray.
2. Adjust the paper-width and paper-length guides outward to make room for the paper.
1 Output tray
2 Paper-width guide
3 Paper-length guide
3. Load up to 20 sheets of paper into the photo tray with the print side down. If you are
using tabbed paper, insert the paper so the tab is closer to you.
4. Adjust the paper-width and paper-length guides inward until they stop at the edges
of the paper. Make sure the stack of paper fits loosely under the tab on the paper-
length guide.
5. Push in the photo tray.
6. Close the output tray.
