GB - 29
SPECIFICATIONS
Model Number 920400 920401
Description Sno-Tek 24 Sno-Tek 26
Engine LCT Storm Force LCT Storm Force
Gross Torque* - ft-lbs (N-m) 9.5 (12.9) 9.5 (12.9)
Displacement - in. (cc) 12.7 (208) 12.7 (208)
High Idle - RPM (min) 3600 ± 50 3600 ± 50
Start Recoil Recoil
Fuel Tank Capacity - qt (Liters) 4.0 (3.8) 4.0 (3.8)
Chute
Chute Rotation Angle 205° 205°
Rotation Control 2.5X Quick Turn 2.5X Quick Turn
Deflector Control Manual Manual
Auger
Snow Clearing Width - in. (cm) 24.0 (61.0) 26.0 (66.0)
Gear Case Aluminum Aluminum
Auger Diameter - in. (cm) 11.0 (27.9) 11.0 (27.9)
Impeller
Impeller Diameter - in. (cm) 12.0 (30.5) 12.0 (30.5)
Impeller Speed (RPM) 1320 1320
Impeller Tip Speed - ft/min (m/min) 4146 (1264) 4146 (1264)
Drive
Blower Drive HA Belt HA Belt
Drive System Disc-O-Matic ® Disc-O-Matic ®
Speeds 6 Forward and 2
Reverse
6 Forward and 2
Reverse
Axle Control Pin-Lock Pin-Lock
Pneumatic Tires - in. 13 x 4-6 15 x 5-6
Size and Weight
Length - in. (cm) 51.9 (131.8) 50.8 (129.0)
Height - in. (cm) 43.3 (110.0) 45.4 (115.3)
Width - in. (cm) 26.4 (67.1) 28.4 (72.1)
Weight - lbs (Kg) 169 (76.7) 174 (78.9)
*Engine output stated in gross torque per SAE J1940 as rated by engine manufacturer.
