HP Pavilion f1523 15 inch Flat Panel Monitor - Manual (Page 35)

Technical Specifications
User’s Guide B–3
vf17, FP17, L1702, f1723, and FP7317 Models
17-inch Flat Panel Monitors
Display
Type 17.0 inches
TFT LCD 43.18 cm
Viewable Image Size 17.0-inch diagonal 43.18 cm
Tilt --5 to 30
o
Maximum Weight
(Unpacked) 13.2 lbs. 6.0 kg (unpacked)
Dimensions (include pedestal)
Height
Depth
Width
15.9 inches
7.8 inches
14.9 inches
405 mm
198 mm
379 mm
Preferred Mode 1280 x 1024 (60 Hz)
Text Mode 720 x 400
Dot Pitch 0.264 (H) x 0.264 (W) mm
Horizontal Frequency 30 to 81 kHz
Vertical Refresh Rate 56 to 76 Hz
Environmental Requirements
Temperature:
Operating Temperature
Non-operating Temperature
41 to 95
o
F
-4 to 140
o
F
5 to 35
o
C
--20 to +60
o
C
Relative Humidity 20 to 80%
Power Source 100 – 240 VAC, 50 – 60 Hz
Power Consumption <50 watts typical
Input Terminal 15-pin D-type connector with cable included.
