B–6 User Guide
Technical Specifications
v7650 17” flat CRT monitor
Screen Size 17”(43 cm) visual diagonal
Viewable screen size 16” (40.6 cm)
Anti-Glare Coating
Dot Pitch 0.25 to 0.28 mm (variable)
Display Area Default 234 x 312 (mm) typical
Display Colors Infinite
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1280 x 1024
1600 x 1200 Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
75 Hz
65 Hz (maximum resolution)
Synchronization (Horizontal) 30 to 86 KHz
Synchronization (Vertical) 50 to 160 Hz
Max Pixel Clock 180 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage
Frequency 100 to 240V AC
50 +3 to 60 +3 Hz
Inrush Current 30 amps @ 120V AC
60 amps @ 220V AC
Power Consumption 75 W (Max.)
Dimension (W x H x D)
Unpacked w/attached base 16.2 x 16.2 x 17 inches (maximum)
410 x 410 x 430 mm (maximum)
