HP mx705 17 inch CRT Monitor - Manual (Page 34)

B–2 User Guide
Technical Specifications
Display Resolutions
640 x 480
640 x 480
640 x 480
720 x 400
800 x 600
800 x 600
1024 x 768
1024 x 768
1152 x 864
1280 x 1024 Refresh Rates
60 Hz
75 Hz
85 Hz
70 Hz
75 Hz
85 Hz
75 Hz
85 Hz (preferred user resolution)
75 Hz
60 Hz (maximum resolution)
Synchronization
(Horizontal) 30 to 70 KHz
Synchronization (Vertical) 50 to 160 Hz
Max Pixel Clock 110 MHz Max.
Input Signal Video RGB Analog Sync. TTL Separate
Video Cable 15-pin D-sub connector
Power Input Voltage
Frequency 100 to 240V AC
50 +3 to 60 +3 Hz
Inrush Current 30 amps @ 120V AC
60 amps @ 220V AC
Power Consumption 75 W (Max.)
Dimension (W x H x D)
Unpacked w/attached
base 16.2 x 16.2 x 17 inches (maximum)
410 x 410 x 430 mm (maximum)
Weight 38 lb Max.
17 kg Max.
Operating Temperature 50
o
F to 95
o
F
10
o
C to 35
o
C
Storage Temperature -22
o
F to 140
o
F
-30
o
C to 60
o
C
