HP Compaq LE1852ms 18.5-inch LED Backlit Monitor - Manual (Page 21)

4 Technical Specifications
NOTE: All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
Specifications
Table 4-1 Specifications
Maximum Weight (Unpacked) 3.2 kg 7.05 lbs
Dimensions (include base)
Height
Depth
Width
33.46 cm
19.18 cm
44.93 cm
13.17 inches
7.55 inches
17.69 inches
Maximum Graphic Resolution 1366 x 768 (60 Hz) analog input
Optimum Graphic Resolution 1366 x 768 (60 Hz) analog input
Power Source 100 – 240 VAC 50/60 Hz
Input Terminal One VGA connector with cable included
Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory
defaults. This monitor automatically recognizes these preset modes and they will appear properly
sized and centered on the screen.
Factory Preset Modes
Table 4-2 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.469 59.94
2 720 Ч 400 31.469 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 48.363 60.004
5 1280 Ч 720 45.0 60.0
6 1280 Ч 1024 63.98 60.02
7 1366 Ч 768 47.712 59.79
Specifications 15
