Chapter 10 Mechanical Data 53
25175H—March 2003 AMD Athlon™ XP Processor Model 8 Data Sheet
Preliminary Information
10.4 Part Number 27648 OPGA Package Dimensions for
AMD Athlon™ XP Processors Model 8 with a CPUID of 681
For AMD Athlon XP processors model 8 with a CPUID of 681,
Table 23 shows the part number 27648 OPGA package
dimensions in millimeters assigned to the letters and symbols
used in the 27648 package diagram, Figure 15 on page 54.
Table 23. Part Number 27648 OPGA Package Dimensions for
AMD Athlon™ XP Processors Model 8 with a CPUID of 681
Letter or
Symbol
Minimum
Dimension 1
Maximum
Dimension 1
Letter or
Symbol
Minimum
Dimension 1
Maximum
Dimension 1
D/E 49.27 49.78 G/H – 4.50
D1/E1 45.72 BSC A 1.917 REF
D2 7.47 REF A1 0.977 1.177
D3 3.30 3.60 A2 0.80 0.88
D4 10.78 11.33 A3 0.116 –
D5 10.78 11.33 A4 – 1.90
D6 8.13 8.68
φP
– 6.60
D7 12.33 12.88
φb
0.43 0.50
D8 3.05 3.35
φb1
1.40 REF
D9 12.71 13.26 S 1.435 2.375
E2 11.33 REF L 3.05 3.31
E3 2.35 2.65 M 37
E4 7.87 8.42 N 453
E5 7.87 8.42 e 1.27 BSC
E6 10.73 11.28 e1 2.54 BSC
E8 13.28 13.83 Mass 2 11.0 g REF
E9 1.66 1.96
Note:
1. Dimensions are given in millimeters.
2. The mass consists of the completed package, including processor, surface mounted parts, and
pins.
