Chapter 10 Mechanical Data 51
25175H—March 2003 AMD Athlon™ XP Processor Model 8 Data Sheet
Preliminary Information
10.3 Part Number 27291 OPGA Package Dimensions for
AMD Athlon™ XP Processors Model 8 with a CPUID of 681
For AMD Athlon XP processors model 8 with a CPUID of 681,
Table 22 shows the 27291 OPGA package dimensions in
millimeters assigned to the letters and symbols used in the
27291 package diagram, Figure 14 on page 52.
Table 22. Part Number 27291 OPGA Package Dimensions for
AMD Athlon™ XP Processors Model 8 with a CPUID of 681
Letter or
Symbol
Minimum
Dimension 1
Maximum
Dimension 1
Letter or
Symbol
Minimum
Dimension 1
Maximum
Dimension 1
D/E 49.27 49.78 E9 1.66 1.96
D1/E1 45.72 BSC G/H – 4.50
D2 7.47 REF A 1.942 REF
D3 3.30 3.60 A1 1.00 1.20
D4 10.78 11.33 A2 0.80 0.88
D5 10.78 11.33 A3 0.116 –
D6 8.13 8.68 A4 – 1.90
D7 12.33 12.88
φP
– 6.60
D8 3.05 3.35
φb
0.43 0.50
D9 12.71 13.26
φb1
1.40 REF
E2 11.33 REF S 1.435 2.375
E3 2.35 2.65 L 3.05 3.31
E4 7.87 8.42 M 37
E5 7.87 8.42 N 453
E6 10.73 11.28 e 1.27 BSC
E7 10.73 11.28 e1 2.54 BSC
E8 13.28 13.83 Mass 2 11.0 g REF
Note:
1. Dimensions are given in millimeters.
2. The mass consists of the completed package, including processor, surface mounted parts, and
pins.
