Reference 268
Product status icons
Event icons
Unknown Tape
FCIP Bridge Or
Gateway
Loop
iSCSI Bridge Or
Gateway
Appliance
HP StorageWorks
Edge Switch 2/16
HP StorageWorks
Edge Switch 2/32
HP StorageWorks
Edge Switch 2/24
Generic HP
StorageWorks switch
or director
HP StorageWorks
Director 2/64
HP StorageWorks
Director 2/140
Table 32 Product Icons (continued)
Icon Description Icon Description
Table 33 Product status icons
Icon Status
No icon Operational
Degraded
Failed
Unknown/Offline
Table 34 Event icons
Icon Description
Informational
Warning
Fatal
