LA2206x Model
Table A-8 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.469 59.940
2 720 Ч 400 31.469 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 48.363 60.004
5 1280 Ч 720 45.00 59.94
6 1280 Ч 1024 63.981 60.02
7 1440 Ч 900 55.935 59.887
8 1680 Ч 1050 65.29 59.954
9 1920 Ч 1080 67.50 60.00
Table A-9 High Definition Video Formats
Preset Timing Name Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 480p 720 × 480 31.469 60
2 576p 720 × 576 31.25 50
3 720p50 1280 × 720 37.5 50
4 720p60 1280 × 720 45 60
5 1080p50 1920 × 1080 56.25 50
6 1080p60 1920 × 1080 67.5 60
LA2306x Model
Table A-10 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.469 59.940
2 720 Ч 400 31.469 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 48.363 60.004
5 1280 Ч 720 45.00 60.00
6 1280 Ч 1024 63.981 60.02
7 1440 Ч 900 55.935 59.887
