HP Compaq LA2306x 23-inch LED Backlit LCD Monitor User Manual

Page 13

Connect a VGA signal cable, DVI-D signal cable, or DisplayPort signal cable. Refer to

Figure 2–7 and

Figure 2–8.

NOTE:

The monitor is capable of supporting either analog or digital input. The video mode is

determined by the video cable used. The monitor will automatically determine which inputs have

valid video signals. The inputs can be selected by pressing the

+/source

button on the front panel

or through the On-Screen Display (OSD) feature by pressing the

button.

●

For analog operation, connect the VGA signal cable to the VGA connector on the rear of the

monitor and the other end to the VGA connector on the computer (cable provided with select

models).

●

For DVI digital operation, connect the DVI-D signal cable to the DVI connector on the rear of

the monitor and the other end to the DVI connector on the computer (cable provided with

select models).

●

For DisplayPort digital operation, connect the DisplayPort signal cable to the DisplayPort

connector on the rear of the monitor and the other end to the DisplayPort connector on the

computer (cable provided with select models).

Connect one end of the provided USB cable to the USB hub connector on the rear panel of the

computer, and the other end to the upstream USB connector on the monitor.

ENWW

Connecting the Cables
