3.

Adjust the monitor’s height to a comfortable position for your individual workstation. The monitor’s

top bezel edge should not exceed a height that is parallel to your eye height. A monitor that is

positioned low and reclined may be more comfortable for users with corrective lenses. The monitor

should be repositioned as you adjust your working posture throughout the work day.

NOTE:

When the monitor is unfolded for the first time, the display head is locked from adjusting

to a full-height position. To adjust the display head to full height, press down on the display head

to unlock it then pull up on the display head to raise it to the full-height position.

Figure 2-12

Adjusting the Height

Figure 2-13

Releasing the Lock Pin and Adjusting the Height (HP LA1956x Model)
