Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults.
This monitor automatically recognizes these preset modes and they will appear properly sized and
centered on the screen.
LA1956x Model
Table A-5 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.469 59.94
2 720 Ч 400 31.469 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 48.363 60.004
5 1280 Ч 1024 63.981 60.02
LA2006x Model
Table A-6 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 640 Ч 480 31.469 59.94
2 720 Ч 400 31.469 70.087
3 800 Ч 600 37.879 60.317
4 1024 Ч 768 48.363 60.004
5 1280 Ч 720 45.0 60.0
6 1280 Ч 1024 63.981 60.02
7 1440 Ч 900 55.935 59.887
8 1600 Ч 900 60.0 60.0
Table A-7 High Definition Video Formats
Preset Timing Name Pixel Format Horz Freq (kHz) Vert Freq (Hz)
1 480p 720 × 480 31.469 60
2 576p 720 × 576 31.25 50
3 720p50 1280 × 720 37.5 50
4 720p60 1280 × 720 45 60
