HP Compaq LA2306x 23-inch LED Backlit LCD Monitor - Manual (Page 26)

A Technical Specifications
NOTE: All specifications represent the typical specifications provided by HP's component
manufacturers; actual performance may vary either higher or lower.
LA1956x Model
Table A-1 LA1956x Specifications
Display
Type
48.3 cm wide screen
Twisted Nematic (TN) LED Backlit LCD
19 inches wide screen
Viewable Image Size 48.3 cm diagonal 19–inch diagonal
Tilt -5 to 25°
Swivel -180 to 180°
Maximum Weight (Unpacked) 4.5 kg 9.92 lbs
Dimensions (include base)
Height (highest position)
Height (lowest position)
Depth
Width
48.64 cm
36.53 cm
19.21 cm
41.78 cm
19.15 inches
14.38 inches
7.56 inches
16.45 inches
Maximum Graphic Resolution 1280 x 1024 (60 Hz)
Optimum Graphic Resolution 1280 x 1024 (60 Hz)
Text Mode 720 × 400
Dot Pitch 0.294 (H) × 0.294 (W) mm
Pixels Per Inch 91.8 PPI
Horizontal Frequency 24 to 83 kHz
Vertical Refresh Rate 50 to 76 Hz
Environmental Requirements Temperature
Operating Temperature
Storage Temperature
5 to 35° C
-20 to 60° C
41 to 95° F
-4 to 140° F
Relative Humidity 20 to 80%
Power Source 100 – 240 VAC 50/60 Hz
20 Appendix A Technical Specifications ENWW
