Port Management
260 Web Tools Version 3.1.x/4.1.x User Guide
Loop Tab Example
An example of the Port Information View > Loop tab is shown in Figure 60 .
Length 62.4u Indicates the length of link using 62.5um multi-mode fiber.
Length cu Indicates the minimum length of link using copper cable.
Vendor Name Indicates the number of the SFP vendor.
Vendor OUI Indicates the unique identifier for the SFP vendor.
Vendor PN Indicates the SFP vendor part number.
Vendor Rev Indicates the SFP vendor revision number.
Serial No: Indicates the SFP vendor serial number.
Date Code Indicates the SFP vendor date code.
Temperature Indicates the module temperature (in Centigrade).
RX Power Indicates the received optical power in micro Watts.
TX Power Indicates the transmitted optical power in micro Watts
(longwave only).
Current Indicates the current laser diode in mAmps.
Voltage Indicates the current voltage in mVolts.
Table 64: Port Information Window SFP Tab Field Descriptions (Continued)
Field Description
