Zone Administration
230 Web Tools Version 3.1.x/4.1.x User Guide
Table 59: QuickLoop Tab Field Descriptions
Field Description
Zoning Method This displays the method you have selected to add members
to the Zoning database. Choose the zoning method in the
View menu. Valid options are:
■
Mixed Zoning
■
Port Zoning
■
WWN Zoning
■
AL_PA Zoning
The Zoning method determines the information displayed in
the Member Selection List.
Enabled Config This field displays the currently enabled zone configuration.
Name Displays existing QuickLoops from this drop-down menu.
Create Button Click to create a new QuickLoop. A dialog box displays;
Enter the name of the new QuickLoop. All names must be
unique and contain no spaces.
Delete Button Click to delete the QuickLoop selected in the Name
drop-down menu. Deleting a QuickLoop automatically
removes it from all configurations.
Rename Button Click to rename the QuickLoop selected in the Name field. A
dialog displays in which you can edit the QuickLoop name.
Renaming a QuickLoop automatically renames it in all
configurations.
Member Selection
List
Select available members from the Member Selection List.
QuickLoop is not supported on either the Core Switch 2/64
or SAN Switch 2/32 switches. However you can manage a
QuickLoop from these switches if it is attached to another
switch in the fabric.
QuickLoop
Members
Displays the current members of a QuickLoop.
Add Member
Button
Click to add a member from the Member Selection List to the
QuickLoop Members. You must select a member within the
Member Selection List for this button to become active.
Remove Member
Button
Click to remove a member from the QuickLoop Members list.
You must select a member within the QuickLoop Members list
for this button to become active.
Message area Displays zoning commit messages on the switch.
QuickHelp Status
Bar
Appears at the bottom of the window. Displays information
for the current window.
