HP StorageWorks 16-EL SAN Switch - Manual (Page 197)

Fabric Management
197 Web Tools Version 3.1.x/4.1.x User Guide
Viewing the Name Server
To view a list of the switches in the Name Server, perform the following steps:
1. Access the switch explorer View.
See “ Perform the following steps to access Fabric Management. ” on
page 189.
2. Select the Name Server icon in the Fabric Toolbar.
See “ Fabric Toolbar ” on page 49.
The Name Server window displays.
3. To sort the events by a particular column, select the column header. To resize a
column, drag the column divider.
Port IP Address Displays the IP address of the fabric port.
Hard Address Displays the hard address of the fabric port.
Member of Zones Displays the zones to which this device belongs. This column
does not update when the table is refreshed. To view updated
zoning information, close and reopen the Name Server
Table.
Table 50: Name Server Description of Columns (Continued)
Column Description
