Performance Monitoring
155 Web Tools Version 3.1.x/4.1.x User Guide
Display Canvas Configurations Example
An example of the Display Canvas Configurations window is shown in Figure 36 .
Table 35: Actions Menu Options Descriptions
Option Description
Save Current
Canvas
Configuration
Select this menu option to save the current Canvas
Configuration to the switch. A dialog box appears; enter a
canvas name and a brief description to save the Canvas
Configuration.
Display Canvas
Configurations
Select this menu option to view all the Canvas Configurations
that have been saved on the switch. A dialog box appears if
graphs have been previously saved to the switch (see
Figure 36 ). Select a Canvas Configuration name from the
dialog box.
Display Resource
Usage
Select this menu option to display all the ports in the switch
and which ports are monitored and which ports are free. This
option requires a Performance Monitor license.
Print All Graphs Use to print all the graphs on a selected canvas.
