Using the HAFM application 26
2. You may specify a new address by typing it in the field, or selecting one from the drop-down
list.
NOTE: Localhost is the default value. The application automatically determines the local IP
address and uses that value as the local host address.
3. The HAFM appliance name displays in the Server Name field.
4. Enter your user ID and password.
5. Select whether you want the application to remember your password the next time you log in.
6. Click Login.
Logging out of HAFM
To log into a different HAFM appliance, you must first log out of the current appliance.
1. Select SAN > Log Out.
You are logged out of the current appliance and the HAFM Log In dialog box displays (
Figure 3 ).
Refer to ” Logging into HAFM ” on page 25 for instructions on logging in to a new appliance.
Adding an appliance
1. Select SAN > Log Out.
The HAFM Log In dialog box displays (See ”
HAFM Log In dialog box ” on page 25.)
2. To add a new appliance, enter the appliance network address in the Network Address field.
TIP: TIP: If the appliance and client are on the same machine, you can type localhost in the
Network Address field.
NOTE: You must have an established login and password account on the new appliance.
The appliance name displays in the Server Name field.
3. Enter your user ID and password.
4. Select whether you want the application to remember your password the next time you log in.
5. Click Login.
The application logs into the appliance located at the specified network address.
Removing an appliance
You can remove appliances from the list in the Log In dialog box.
1. If you are logged into an appliance, select SAN > Log Out. If you do not have the
application open, start the application.
The HAFM Log In dialog box appears (
Figure 3 ).
