Configuring HAFM through a firewall 174
NOTE: If the firewall prevents the server from connecting to arbitrary ports on the client, then just
force the export port of the client (
-Dsmp.client.export.port=YYYY
).
HAFM_sc.bat
Place the parameter
-Dsmp.server.export.port=XXXX
in the server area of the file, and the
parameter
-Dsmp.client.export.port=YYYY
, in the client area of the file, where
XXXX
and
YYYY
are any TCP port numbers not used by another application. Although the server port number
XXXX
could match the client port number
YYYY
, this is not necessary. Add the parameters after the
%CLASSPATH%
parameter. The following example shows the edited file with the added parameters
in bold:
setlocal
pushd %~dp0\..
call bin\set_cp.bat
...............
rem HAFM Server
start %JAVA_HOME%\bin\HAFMServer.exe -server -Xmx512m -Xminf.15 -Xmaxf.35
-classpath %CLASSPATH% -Dsmp.Mp.max=512 -Dsmp.autodiscovery=false
-Dsmp.mpi.test -Dsmp.deployment.prefix=Server/ -Dsmp.zoning=legacy
-Dsmp.zoning.wait.timeout=180000 -Dsmp.webServer
-Dsmp.server.export.port=XXXX
-Dsmp.flavor=%APP_FLAVOR% Server
rem HAFM Server Debug Mode
rem start %JAVA_HOME%\bin\HAFMServerD.exe -server -Xmx512m -Xminf.15
-Xmaxf.35 -classpath %CLASSPATH% -Dsmp.Mp.max=512 -Dsmp.autodiscovery=false
-Dsmp.mpi.test -Dsmp.deployment.prefix=Server/ -Dsmp.zoning=legacy
-Dsmp.zoning.wait.timeout=180000 -Dsmp.debug -Dsmp.webServer
-Dsmp.server.export.port=XXXX
-Dsmp.flavor=%APP_FLAVOR% Server
:client
rem HAFM Client
start %JAVA_HOME%\bin\HAFMClient.exe -Xmx256m -Xminf.15 -Xmaxf.35 -classpath
%CLASSPATH% -Dsun.java2d.noddraw=true -Dsmp.fabricPersistenceEnabled=true
-Dsmp.Mp.max=256 -Dsmp.deployment.prefix=Client/
-Dsmp.client.export.port=YYYY
-Dsmp.flavor=%APP_FLAVOR% Client
rem HAFM Client Debug Mode
rem start %JAVA_HOME%\bin\HAFMClientD.exe -Xmx256m -Xminf.15 -Xmaxf.35
-classpath %CLASSPATH% -Dsun.java2d.noddraw=true
-Dsmp.fabricPersistenceEnabled=true -Dsmp.Mp.max=256
-Dsmp.deployment.prefix=Client/ -Dsmp.debug -Dsmp.client.export.port=YYYY
-Dsmp.flavor=%APP_FLAVOR% Client
:end
popd
endlocal
HAFM_c.bat
HAFM_c.bat
starts the Client only.
HAFM_c.bat
starts the Client only and is installed with the
Client software. Edit the file to include the parameter
-Dsmp.client.export.port=YYYY
. Add
