Connecting the Cables
1.
Place the monitor in a convenient, well-ventilated location near the computer.
2.
Connect a signal cable.
NOTE:
The monitor is capable of supporting analog, digital, or HDMI input. The video mode is
determined by the video cable used. The monitor will automatically determine which inputs have
valid video signals. The inputs can be selected by pressing the
+/source
button on the front panel
or through the On-Screen Display (OSD) feature by pressing the
Menu
button.
●
For analog operation, use a VGA signal cable. Connect the VGA signal cable to the VGA
connector on the rear of the monitor and the other end to the VGA connector on the
computer.
Figure 2-4
Connecting a VGA Signal Cable (provided with select models)
6
Chapter 2 Setting Up the Monitor
