Component identification 11

Position Function

Default

8 Reserved

Off

*To access redundant ROM, set S1, S5, and S6 to ON.

Local I/O cable

Item Connector Description

1

Server blade

For connecting to the local I/O cable

connector on the server blade front panel

2

Video

For connecting a video monitor

3

USB

For connecting up to two USB devices

4

Serial

For trained personnel to connect a null modem
serial cable and perform advanced diagnostic

procedures
