90 Configuring Core Switch 2/64, SAN Director 2/128, and 4/256 SAN Director
CP blades
CP blades determine the director type:
• If CP1 blades are installed, the director is a Core Switch 2/64.
• If CP2 blades are installed, the director is a SAN Director 2/128.
• If CP4 blades are installed, the director is a 4/256 SAN Director.
HP recommends that each HP StorageWorks director have only one type of CP blade installed and that
each CP (primary and secondary partition) maintains the same firmware version.
Table 15 HP StorageWorks director terminology and abbreviations
Term Abbreviation Blade ID Definition
Core Switch 2/64 CP blade CP1 1 The first-generation CP blade provided with the Core
Switch 2/64. This CP supports 1- and 2-Gbit/sec port
speeds. It supports only the dual domain configuration
within the chassis.
SAN Director 2/128 CP blade CP2 5 The second-generation CP blade provided with the SAN
Director 2/128. This CP supports 1- and 2-Gbit/sec
port speeds. It supports both the dual domain and a
single domain configuration within the chassis.
4/256 SAN Director CP blade CP4 16 The second-generation CP blade provided with the
4/256 SAN Director. This CP supports 1-, 2-, and
4-Gbit/sec port speeds, as well as 16 and 32-port
blades.
16-port 2-Gbit/sec port blade FC-16 2 The first-generation HP StorageWorks director 16-port
blade supporting 2-Gbit/sec port speeds. This port
blade is compatible only with the Core Switch 2/64 or
SAN Director 2/128 CP blades.
16-port 2-Gbit/sec port blade FC2-16 4 The second-generation HP StorageWorks director 16
port blade supporting 1- and 2-Gbit/sec port speeds.
This port blade is compatible only with the SAN Director
2/128 or 4/256 SAN Director CP blades.
16-port 4-Gbit/sec port blade FC4-16 17 The third-generation HP StorageWorks director 16 port
blade supporting 1-, 2-, and 4-Gbit/sec port speeds.
This port blade is compatible only with the SAN Director
2/128 and 4/256 SAN Director CP blades. FC4-16
blades do not support private devices.
32-port 4-Gbit/sec port blade FC4-32 18 A 32-port HP StorageWorks director port blade
supporting 1-, 2-, and 4-Gbit/sec port speeds.This port
blade is compatible only with the 4/256 SAN Director
CP blades. FC4-32 blades do not support private
devices.
