Fabric OS 5.x administrator guide 155

For example:

NOTE:

See

Viewing the port log

” on page 137 for overview information about the output of the

portLogDump

command.

Identifying media-related issues

This section provides procedures that help pinpoint any media-related issues in the fabric. The tests listed

in

Table 26

are a combination of structural and functional tests that can be used to provide an overview of

the hardware components and help identify media-related issues.

Structural tests perform basic testing of the switch circuit. If a structural test fails, replace the main

board or port blade.

Functional tests verify the intended operational behavior of the switch by virtue of running frames

through ports or bypass circuitry.

sw094135:admin> portlogdumpport 10

time task event port cmd args

-------------------------------------------------

12:38:21.590 SPEE sn 10 WS 00000000,00000000,00000000

12:38:21.591 SPEE sn 10 WS 000000ee,00000000,00000000

12:38:21.611 SPEE sn 10 WS 00000001,00000000,00000000

12:38:21.871 SPEE sn 10 NC 00000002,00000000,00000001

12:38:21.872 LOOP loopscn 10 LIP 8002

12:38:22.171 LOOP loopscn 10 TMO 2

12:38:22.171 INTR pstate 10 LF2

12:38:22.172 INTR pstate 10 OL2

12:38:22.172 INTR pstate 10 LR3

12:38:22.172 INTR pstate 10 AC

12:38:22.172 PORT scn 10 11 00000000,00000000,00000002

12:38:22.311 PORT scn 10 1 00000000,00000000,00000001

12:38:22.311 PORT debug 10 00000001,00654320,00000001,00000000

12:38:22.311 PORT debug 10 00000001,00654320,00000002,00000000

12:38:22.311 PORT debug 10 00000001,00654320,00000003,00000000

12:38:22.313 PORT Tx 10 164 02fffffd,00fffffd,025effff,10000000

12:38:22.314 PORT debug 10 00000001,00654320,00000003,00000000 *
7

12:38:28.312 PORT Tx 10 164 02fffffd,00fffffd,028fffff,10000000

12:38:34.312 PORT Tx 10 164 02fffffd,00fffffd,0293ffff,10000000

12:38:40.312 PORT Tx 10 164 02fffffd,00fffffd,0299ffff,10000000

12:38:46.312 PORT Tx 10 164 02fffffd,00fffffd,029bffff,10000000

12:38:52.312 PORT Tx 10 164 02fffffd,00fffffd,029dffff,10000000

12:38:58.312 PORT Tx 10 164 02fffffd,00fffffd,02acffff,10000000

12:39:04.322 INTR pstate 10 LR1

12:39:04.323 INTR pstate 10 LR3

12:39:04.323 INTR pstate 10 AC

12:39:04.323 PORT scn 10 11 00000000,00000000,00000002

sw094135:root>
