Configuring Zones
84 Embedded Web Server User Guide
zoning through a multiswitch fabric
Figure 22: Zoning through a multiswitch fabric
Controlling Access at the Switch
A port binding feature is available on switches and directors that allows you to
bind a specific switch or director port to the WWN of an attached device for
exclusive communication. This Port Binding feature is available through the Port
Binding tab, which is under the Security tab of the Configure page view.
Zone 1
Interswitch Link
Zone 3
Zone 2
Director
Director
Director
