5. Apply a small spot of foam-safe CA to the bottom of
the control horn and insert it into the cut in the aileron. Press a
nylon backplate on the backside of the control horn as shown.
❏ ❏
6. Install a black nylon snap keeper onto the pushrod
at the control horn.
❏
7. Install the rudder and elevator pushrods in the same
way as the ailerons. Use the 5-3/4" [146 mm] prebent
pushrod for the rudder and the 2-1/2" [64 mm] prebent
pushrod for the elevator.
❏
1. Connect the output wires of your ESC to the motor.
Check the direction of the motor before permanently
installing it.
❏
2. Install the ESC as shown using a small section of hook
and loop tape. Place the hard “hook” side in the provided
cutout in the fuselage and the softer “loop” side on the back
of the ESC. If your ESC has a BEC switch, install it in the
provided cutout. For some electronic speed controls, it may
be necessary to trim the foam slightly to allow for wire
clearance and switch mounting.
❏
3. Slide the gearbox onto the square wood stick in the
nose. Secure it with the supplied #2 x 3/8" [9.5 mm] screw.
Install the Motor & Speed Control
11
