Component identification 8

Rear panel LEDs and buttons

Item Description

Status

1

NIC status LED

Solid green = Link to network

Flashing green (1 Hz/cycle per sec) = Network active
Off = No network activity

2

NIC link LED

Solid green = Link exists

Off = No link exists

3

Power supply LED Solid green = System on/System in standby

Off = No power present

System board components
