External Controls
A B C D E F
G
Mute
Menu
Auto
Power
A
– (minus) button
Navigates backward through the OSD menu and decreases adjustment levels.
If the OSD menu is inactive, activates the Volume decrease.
B
+ (plus) button
Navigates forward through the OSD menu and increases adjustment levels.
If the OSD menu is inactive, activates the Volume increase.
C
Menu button
Opens, selects, or exits the OSD menu.
D
Mute button
Turns sound on or off.
E
Auto button
Automatically fine-tunes the image quality.
F
Power button
Turns the monitor on or off.
G
Power LED
Fully powered = green
Sleep mode = amber
Sleep timer mode = flashing amber
12
