HP v216 21.6 inch LCD Monitor - Manual (Page 10)

Wall Mounting Arm
Preparing to Install a Wall Mounting Arm (Not supplied)
This monitor can be attached to a wall mounting arm that you purchase separately.
CAUTION: Before disassembling the monitor, turn off the monitor power, and disconnect all
power, video, and audio cables.
1 Disconnect the cables from the monitor.
2 With the panel face-down on a protected surface, remove the screws and the pedestal/base attachment.
3 Follow the manufacturer’s instructions to assemble the wall mounting arm.
Installing a Wall Mounting Arm
1 Set the monitor screen down on a flat, soft, protected surface.
2 Place the wall mounting arm onto the back of the monitor. Line up the holes of the arm with the mounting holes
in the back of the monitor.
3 Insert four screws into the mounting holes and tighten.
4 Reconnect the cables. Refer to the user’s manual that came with the wall mounting arm (purchased separately)
for instructions on attaching it to the wall.
10
