Configuring HAFM through a firewall
204
The HAFM_sc.bat file starts both the client and server and is installed on a computers with the
HAFM appliance software. The HAFM_c.bat file starts the client only and is installed with the
client software.
NOTE:
If the firewall prevents the server from connecting to arbitrary ports on the client, then just
force the export port of the client (-Dsmp.client.export.port=YYYY).
HAFM_sc.bat
Place the parameter -Dsmp.server.export.port=XXXX in the server area of the file, and the
parameter -Dsmp.client.export.port=YYYY, in the client area of the file, where XXXX and
YYYY
are any TCP port numbers not used by another application. Although the server port number
XXXX
could match the client port number YYYY, this is not necessary. Add the parameters after the
%CLASSPATH%
parameter.
The following example shows the edited file with the added parameters in bold:
setlocal
pushd %~dp0\..
call bin\set_cp.bat
...............
rem HAFM Server
start %JAVA_HOME%\bin\HAFMServer.exe -server -Xmx512m -Xminf.15 -Xmaxf.35
-classpath %CLASSPATH% -Dsmp.Mp.max=512 -Dsmp.autodiscovery=false
-Dsmp.mpi.test -Dsmp.deployment.prefix=Server/ -Dsmp.zoning=legacy
-Dsmp.zoning.wait.timeout=180000 -Dsmp.webServer
-Dsmp.server.export.port=XXXX
-Dsmp.flavor=%APP_FLAVOR% Server
rem HAFM Server Debug Mode
rem start %JAVA_HOME%\bin\HAFMServerD.exe -server -Xmx512m -Xminf.15
-Xmaxf.35 -classpath %CLASSPATH% -Dsmp.Mp.max=512 -Dsmp.autodiscovery=false
-Dsmp.mpi.test -Dsmp.deployment.prefix=Server/ -Dsmp.zoning=legacy
-Dsmp.zoning.wait.timeout=180000 -Dsmp.debug -Dsmp.webServer
-Dsmp.server.export.port=XXXX
-Dsmp.flavor=%APP_FLAVOR% Server
:client
rem HAFM Client
start %JAVA_HOME%\bin\HAFMClient.exe -Xmx256m -Xminf.15 -Xmaxf.35 -classpath
%CLASSPATH% -Dsun.java2d.noddraw=true -Dsmp.fabricPersistenceEnabled=true
-Dsmp.Mp.max=256 -Dsmp.deployment.prefix=Client/
-Dsmp.client.export.port=YYYY
?Dsmp.flavor=%APP_FLAVOR% Client
rem HAFM Client Debug Mode
rem start %JAVA_HOME%\bin\HAFMClientD.exe -Xmx256m -Xminf.15 -Xmaxf.35
-classpath %CLASSPATH% -Dsun.java2d.noddraw=true
-Dsmp.fabricPersistenceEnabled=true -Dsmp.Mp.max=256
-Dsmp.deployment.prefix=Client/ -Dsmp.debug -Dsmp.client.export.port=YYYY
?Dsmp.flavor=%APP_FLAVOR% Client
:end
popd
endlocal
