Optional HAFM features 124
Event triggers
Event triggers monitor system events and fire when the specified conditions exist. You can define the
phrases (rows) and their logical relationships. The phrases filter all the event context properties to
identify those events that you want to trigger the event.
Event triggers also allow you to set time limits so that the trigger occurs only if the event happens
within a certain time and date range. For example, you can specify that all offline events between 5
p.m. and 8 a.m. trigger e-mail message and log actions to take place.
Schedule triggers
Schedule triggers monitor the system clock and fire when the specified time and date conditions are
met.
Schedule triggers can be set to fire:
• Daily
• Weekly
• Monthly
• One time only
• Hourly
CAUTION: Once you have chosen a schedule type and added the first phrase, do not change
types or you can lose your work.
Actions
You can configure multiple actions to be performed when the specified triggers are fired.
The following actions are possible:
• E-mail—Send an e-mail to specified recipients.
• Export—Export data.
• Launch—Launch an application using a script.
• Log—Add an entry to the Master Log file and window display.
• Message—Display a message to all open clients.
• Pause—Insert a pause between actions.
• Report—Generate a report.
• Sound—Play a sound.
The launch and sound actions point to information in a file. You can select an existing option from a
list, or add options to the list as follows:
• For a launch action, add your script files to the Install_Home\Server\LaunchScripts
directory.
• For a sound action, add your sounds to the Install_Home\Server\Sounds directory.
