Ultra Start 45xx Series - Manual (Page 8)

Page 8
Auxiliary Output 1 (Optional)
Siren On/Off
Auxiliary Output 2 (Optional)
Auxiliary Output are optional outputs from the system. These outputs
Can be used to activate such things as power window roll-up/ down
modules or to open and close a power sun roof.
To Activate Auxiliary #1
1. Press and hold buttons #1 and #3.
2. The park lights will flash and the siren will chirp 1 time.
3. The auxiliary output will stay activated until the button are released.
When this feature is programmed on the siren will only activate
when the alarm is triggered or if the Car Finder is activated.
1. Press and hold button #4 until the Timer Mode icon begins to
flash.
2. Press and release button #1 four times or until the siren icon
begins to flash.
3. To turn the siren Off press button #2. Press button #4 to exit.
To turn the siren back on, press button #3 while the siren icon
is flashing.
Auxiliary Output are optional outputs from the system. These outputs
Can be used to activate such things as power window roll-up/ down
modules or to open and close a power sun roof.
To Activate Auxiliary #2
1. Press and hold buttons #2 and #3.
2. The park lights will flash and the siren will chirp 1 time.
3. The auxiliary output will stay activated until the button are released.
1 2 3
4
1 2 3
4
1 2 3
4
OWNER’S GUIDE
2way REMOTE STARTER/ ALARM
