Idler bearing assembly – ADC ML-75 User Manual
Page 21
19
Telephone: (508) 678-9000
Fax: (508) 678-9447
Illus. No.
Part No.
Qty.
Description
1
100106
1
5L-690 V-Belt (basket [tumbler] to idler)
2
101140
1
14” x 3” Compound Pulley
3
100117
1
4L-620 V-Belt (idler to motor)
For Non-Reversing Models ONLY
100114
1
4L-630 V-Belt (idler to motor)
For Reversing Models ONLY
4
154301
2
5/16-18 x 1” Allen Setscrew
5
100705
1
3/16” x 3/16” x 1-3/8” Key
6
882576
1
Idler Bearing Assembly Complete
(includes illus. nos. 5 through 12)
7
801009
1
Idler Square Washer
8
152004
1
5/16-18 Hex Nut
9
150509
1
5/16-18 x 3” Hex Head Machine Bolt
Idler Bearing Assembly
