Introduction
Connection Ports
1. RS232 Connector
2. USB Connector
3. Monitor Loop-through Output Connector (VGA-Out)
4. Audio Input Connector
5. Composite Video Input Connector
6. S-Video Input Connector
7. PC Analog Signal/HDTV/Component Video Input Connector
8. DVI Input Connector (for Digital signal with HDCP function) (Op-
tional)
9. Kensington
TM
Lock Port
Below items are for PD525PW/PD527W only:
10. Lan (RJ45 Port for 10/100M Ethernet)
11. Audio Output Connector
12. Reset Button
13. Status Indicator
14. Antenna
1
6
2
5
3
4
7
9
14
For PD525PW/
PD527W only
11
12
13
10
8
