Technical Specification
Power Behind the Storage
For More Information:
Hardware Specifications
Applications
•
Support for IT server and digital media workgroup solutions requiring high-bandwidth and data
protection. Applications include audio/video, VOD, fixed content, database and other data intensive
environments.
Maximum Transfer Rate
•
Up to 3-Gb/sec per port
Advanced Capabilities
•
Device support for SAS, SATA and SATA II
•
SES Support
•
S.M.A.R.T Support
•
Support for Staggered drive spin-up
•
Pass-through mode to support tape devices
•
Support for RAID levels 0, 1, 4, 5, 6, 10, 40, 50, 60, JBOD and DVRAID
•
On-line capacity expansion
•
Hot spare, auto-rebuild
•
Native Command Queuing
•
Cache memory—256MB ECC protected memory
•
User friendly GUI for RAID setup
•
External LEDs for on-line status
PCI Bus Specifications
•
x8 PCI Express host interface
•
Supports PCI Express Base Spec 1.0a
Connectivity
•
Easy-to-install full height connection bracket; low-profile bracket included in Finished Goods packaging
•
Two x4 External Mini SAS (SFF-8088) connectors
Software Specifications
Driver Support
•
Windows ® Server 2003, 2008, XP, Vista
•
Mac ® OS X (10.4.x & 10.5.x)
•
Linux (Fedora, Red Hat and SuSE)
Agency Approvals
Safety and Environmental
•
FCC Rules, Part 15, Class B
•
CE Mark: CISPR 22:2002
•
EN55022:2002, Class B
Compliancy
•
RoHS Compliant
Environmental & Physical Specifications
Dimensions
•
Conforms to PCI low-profile form factor specifications
•
Length 6.600”
•
Height 2.713”
Operating Environment
•
Temperature: 0-40° C (32°-104°F)
•
Humidity: 5 - 95% non-condensing
Storage Environment
•
Temperature: -40°-70°C (-40°-157°F)
•
Humidity: 5 - 95% non-condensing
Power
•
12V @ 1.05A max.
•
3.3V @ 0.45A max.
Airflow
•
150 lf/m (min) recommended
Ordering Information
Model Number
•
ESAS-R380-000 (RoHS)
ExpressSAS Low-Profile RAID Adapter
3-Gb SAS/SATA II Connectivity with Integrated RAID Support
ExpressSAS R380 RAID Adapter
