AXIS 215 PTZ/AXIS 215 PTZ-E - Technical Specifications
45
Important!
•The figures displayed here are the values as delivered by the camera. If other restrictions are currently in force, (e.g. band-
width limitation) these values might not correspond to those actually received by the client.
•For Motion JPEG, these values will only be accurate as long as no frame rate limit has been specified.
Frame rates - Motion JPEG
The following test results show the frame rates in frames/second (fps) for Motion JPEG streams from the AXIS
215 PTZ/AXIS 215 PTZ-E, using a compression level of 50%. Note that these values are guidelines only - actual
values may vary.
Frame rates - MPEG-4
The following test results show the frame rates in frames/second (fps) for MPEG-4 streams from the AXIS 215
PTZ/AXIS 215 PTZ-E. Note that these values are guidelines only - actual values may vary.
The MPEG-4 test conditions:
• Compression level = 50%
• Video Object Type = Advanced Simple
• GOV structure = IP*
*Note that setting the GOV structure to use “I-frames only” will increase the frame rate.
Bandwidth
As there are many factors affecting bandwidth, it is very difficult to predict the required amounts. The settings
that affect bandwidth are:
• the image resolution
• the image compression
• the frame rate
• the MPEG-4 object type
• the MPEG-4 GOV structure
• the audio settings (AXIS 215 PTZ only)
There are also factors in the monitored scene that will affect the bandwidth. These are:
• the amount of motion
• the image’s complexity
• the lighting conditions.
Resolutions 60Hz/50Hz
4CIF 30/25 fps
2CIF expanded 30/25 fps
2CIF 30/25 fps
CIF 30/25 fps
QCIF 30/25 fps
Resolutions 60Hz/50Hz
4CIF 25/21 fps
2CIF expanded 25/21 fps
2CIF 30/25 fps
CIF 30/25 fps
QCIF 30/25 fps
