7
CHAPTER 2:
Using Multiple Displays
Connecting Your Monitors
Your Radeon
®
X1650 PRO graphics card provides hardware support for
two DVI-I monitors and a VGA monitor using the supplied DVI-I-to-VGA
adapter. It also provides TV output via an S-Video Out connector.
Connections and Adapters for the Radeon ® X1650 PRO Card
1 Standard VGA Monitor Connector. To connect a VGA monitor
to the DVI-I connector, plug the supplied DVI-I-to-VGA adapter
into the DVI-I connector, then plug your monitor cable into the
adapter.
2 DVI-I-to-VGA Adapter.
3 DVI-I Connection. To connect a digital display.
