ARCHITECT AND ENGINEER SPECIFICATIONS
The metal enclosure shall be Atlas Sound Model ___________ or approved equal designed specifically to match with Atlas Sound loudspeaker baffle
package ________. Enclosure shall be of welded 20 gauge CRS or 18-gauge stainless steel construction as specified.
© 2006 Atlas Sound LP
Printed in U.S.A.
00606
ATS002382 RevA 6/06
SL1-2088
Model
Description
A
B
C
D
E
F
SEA-I8S
Enclosure Surface Slanted for I8S
11.75"
298mm
11.71"
297mm
5"
127mm
3"
76mm
SEST-I8S
Enclosure Surface Straight for I8S White
11.59"
294mm
11.63"
295mm
4"
102mm
FEST-I8S
Enclosure Flush Straight for I8S
10.63"
270mm
10.63"
270mm
3.75"
95mm
17.63"
448mm
15.5"
394mm
SEA-I8SC
Enclosure Surface Slanted for I8SC
I8SCM
13"
330mm
14.41"
366mm
5"
127mm
2.5"
64mm
SEST-I8SC
Enclosure Surface Straight for 18SC,
I8SCM White
13.13"
334mm
14.63"
372mm
4"
102mm
FEST-I8SC
Enclosure Flush Straight for I8SC,
I8SCM
11.59"
294mm
13.13"
334mm
4"
102mm
18.63"
473mm
16.5"
419mm
SEST-IH
Enclosure Surface Straight for IH-VP
Straight Surface White
11"
279mm
11"
279mm
6"
152mm
FEST-IH
Enclosure Flush Straight for
IH-VP Straight Surface White
9.63"
245mm
9.63"
245mm
6"
152mm
16.63"
422mm
14.5"
368mm
�
�
�
����������
�����������
�
�
�
�
�
�
�����������
�
�
�
�
�
�
����������
�����������
�
�
�
�
�
�
�����������
�
�
�
